PG2340 Mini Counting Sensor

PG2340 Mini Counting Sensor Specification

Product Type
Counting sensor

Material
Metal

Input
10-30V

Output
NPN / PNP

Function
Counting small objects

Usage
Industrial

Accuracy
1.5 mm

Resolution
High

Voltage
10-30V Volt (v)

Weight
60 Grams (g)

Warranty
Yes

PG2340 Mini Counting Sensor Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Paypal, Telegraphic Transfer (T/T)

Supply Ability
1000 Pieces Per Month

Delivery Time
7 Days

Main Export Market(s)
Asia, Central America, Eastern Europe, Australia, North America, Middle East, South America, Western Europe

Certifications
CE

About PG2340 Mini Counting Sensor

Model	PG2340	PG3040
Sensing area	23x40mm	31x40mm
Resolution	1.5mm	2mm
Power supply	10-30VDC (including voltage ripple of 10%(p-p) Max.)
Response time	1ms
Indicator	Power indicator(green), operation indicator (red), alarm indicator (yellow)
Current consumption	25mA
Load current	Max. 100mA
Output	NPN / PNP
Circuit protection	Power on delay, reverse polarity protection, output short-circuit protection
Ambient illumination	Incandescent lamp: 5,000lx Max.; sunlight: 50,000lx Max.
Ambient temperature	Operation: -20-65; storage: -30-80 (with no icing and condensation)
Ambient humidity	Operation: 45-85% RH; storage: 35-95% RH (with no condensation)
Protection degree	IEC IP64
Connection method	Cable
Line color definition	Brown: power supply; blue: GND; black: operation output; white: alarm output
Material	AL6061+PMMA
Accessory	Manual
Weight	60g	70g

High Precision Counting

With its 1.5 mm accuracy and high-resolution sensing capabilities, the PG2340 excels at detecting and counting even the smallest objects. Designed for environments where precision is crucial, this sensor ensures optimal results for automated processes in diverse industrial applications.

Versatile Industrial Integration

The PG2340 supports both NPN and PNP outputs, making it highly adaptable to a wide variety of industrial systems. Its standard input voltage of 10-30V streamlines integration and installation for manufacturers and suppliers across multiple sectors.

FAQs of PG2340 Mini Counting Sensor:

Q: How does the PG2340 Mini Counting Sensor operate?

A: The PG2340 uses high-resolution optics and electronics to accurately detect and count small objects as they pass through its sensing area, providing quick and reliable output signals in either NPN or PNP format.

Q: What are the main benefits of using this sensor in industrial environments?

A: This sensor ensures high accuracy (1.5 mm), robust metal construction, and compatibility with different control systems, making it ideal for enhancing efficiency, reducing errors, and increasing productivity in counting-based automation tasks.

Q: When should I consider installing the PG2340 sensor?

A: Install the PG2340 whenever you require precise counting of small objects in manufacturing, packaging, or assembly lines, especially where compact size and high accuracy are essential.

Q: Where can this sensor be applied most effectively?

A: The sensor is best suited for industrial settings such as automated production lines, conveyors, and machinery used in object tracking, packaging, or batch processing.

Q: What is the typical process for connecting the PG2340 sensor to a control system?

A: Simply connect the sensors power input (10-30V), select the desired NPN or PNP output mode, and integrate the output into your existing control or automation system. Detailed wiring instructions are provided in the product manual.

Q: How is the sensor maintained for long-term usage?

A: Routine inspections for cleanliness and secure connections are recommended. Given its metal housing, the sensor is durable, but periodic checks will help maintain optimal performance throughout its lifespan.
